| Power Supply | 3P+N+PE |
|---|---|
| Rated Voltage Input | AC380～450V |
| Rated Current Input | 1x32A(16A ,13A,10A Adjustable) |
| Output Voltage | AC380～450V |
| Maximum Current Output | 1x32A(16A ,13A,10A Adjustable) |
| Rated Power Output | 1x22KW(MAX) |
| Charger Connector | Type 2 socket |
| Cable Length | NA |
| Material | Galvanized sheet powder-coated metal housing |
| Colour | BLACK |
| EVEC App | Optional |
| Ingress Protection | IP54 |
| Certification | CE/ UKCA |
| Certification Standard | EN IEC 61851,EN 62196 |
| Installation | Floor mounted |
| Mounting options | Ground bases available |
| Work Temperature | -25℃~50℃ |
| Work Humidity | 3%~95% |
| Work Altitude | <2000m |
| Production Dimension (HxWxD) mm | 1200*250*250 |
